Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes (1842)

Brooks, S. H. (Samuel H.) · London : T. Kelly · leaf 48

An illustration from Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes, 1842, leaf 48
a bridge built of brick, over which the railwayis supposed to run. Fig. 2 is the transverse section of a portion of the same.Fig. 3 is a section of the wing-wall.Fig. 4 is a portion of the same, the reverse way.Fig. 5 is a half plan of the foundations. Plate XV. Fig. 1 is the half elevation of a… … ^ t r_ p-

Public buildings · Architecture
