Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes (1842)

Brooks, S. H. (Samuel H.) · London : T. Kelly · leaf 64

An illustration from Select designs for public buildings; consisting of plans, elevations, perspective views, sections, and details, of churches, chapels, schools, alms-houses, gas-works, markets, and other buildings erected for public purposes, 1842, leaf 64
ndow-heads. Fig. 2 shows the method of constructing the window-sill. Fig. 3 is an elevation of the head of the window. Fig. 4 is an elevation of the sill of the same. Fig. 5 is a plan of one of the muUions. Fig. 6 is a plan of one of the jambs. Fig. 7 is a plan of one of the door jambs. Fig. 8 is a…

Public buildings · Architecture

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
