Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 104
between the spring under static and maximum load;at the latter point its leaves should be nearly straightened understress; beyond that point, as they are bent backward and down-ward, the point of ultimate strength, involving loss of elasticityand breakage, is rapidly approached. It follows,… … Fig. 81.—Spring Compensating Steering Device used on the Oldsmobile Carriage.The cut shows the spindle of the steering lever with its attached arm joining thetransverse link at about the centre of its length. The attachment of one of theside springs is shown near the right-hand end of the axle. The…
Automobiles
