Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 334
ll length of itsstroke and still leave enough of the rod outside thecylinder to fasten it to the crosshead. To avoidleakage of steam through the hole in the cylinderhead, through which the piston rod protrudes, 2. stiff-ing box is attached to the cylinder head. It isevident that the extreme length… … 364 ROGERS DRAWING AND DESIGN. fastened to the engine bed, or form a part of thebed casting, in one piece, and which are called thecross/lead gtiides; these must be set absolutelyparallel to the axis of the cylinder. The steam cylinder, as well as all other parts ofthe steam engine mechanism, is…
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
