joined to the tire, anda rupture often follows at that point. Even were it possible to 128 SELF-PROPELLED VEHICLES. obviate the last-named accident, it is evident that the service ofa tire, thus loosened by the creeping process is impaired. More-over, it would inevitably roll sideways from the rim… … Fig. 109.—Showing the method of removing the case tube of a Dunlop tire. Two tools,like that shown at top of the figure, are inserted between the rim channel wall andthe tire, as at A, after deflation. The edge of the tube, being pushed into the centralchannel, is then raised, as at B. When one…
