Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 164
Fig. 124. Fig. 125. Figs. 124 and 125.—Two Forms of Expanding Band Brake. In the first figure, the gear, G,nas an internal bearing surface, within which is the band, C, pivoted at A, a pointseparate from G. The arm, B, of the bell crank, B D, being moved to the left, spreadsapart the two links, E…
Automobiles
