tical disk, forged in one piece with it, so as to rest on theinside face of the wheel. This flange was pierced at intervals tohold bolts, each penetrating one of the spokes, and forming thehub with a plate of corresponding diameter nutted upon theouter face of the wheel. The through axle shaft,… … Fig. 17.—Churchs Three-wheel Coach (1833), drawn from an old woodcut, showing for-ward spring wheel mounted on the steering pivot. similarly shaped and disposed lugs, and the driving was effectedby the former pair, turning with the axle spindle, engaging thelatter pair, thus combining the…
