Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 297
ing of the induction coil to binding-post, B1, andwire, B, which is in electrical contact with the spindle, F, of therotating disc, G. The circuit is closed, as already stated, when-ever the brass arc, H, on the periphery of the disc is brought intocontact with the button, K, carried on the spring,… … Fig. 200.—Type of French Wire-Contact Circuit Interrupter used on Cir-cuits having- Magnetic Tremblers on the Coils. As shown, the rollercomes into contact with the arc-shaped plates representing terminalsof each of the four coil and plug circuits, making each of tLjm in suc-cession. G, on the…
Automobiles
