Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 347
dary camshafts, by which alsothe make-and-break of the electric sparking circuit is made byspecial rods, as shown in the section. As may be also seen, theinlet valves open, at right angles to the exhaust. The Stevens=Duryea Motor.—Another engine of the doubleopposed cylinder type is that used on… … Pig. 248.—Stevens-Duryea Motor. Two opposed cylinders, working oncranks at 180 degrees. The crank shaft terminates in an integral discto which the flywheel is secured by bolts in the outer circle of holes, „ while the change-gear shaft flange is secured by bolts in the innercircle of holes. Bore,…
