Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 446

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 446 — D,C AMMETER V Fig. 330.—Index Scales of a Voltmeter and an Ammeter for Measuring thePressure and Intensity on a Direct-current Electrical Circuit. tery terminals, both in charging and discharging, while, in theammeter scale, the space to the left indicates the amperage of thecharging current, and…

Automobiles

Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
