Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 588
the figure, onaccount of being rigidly secured to the head at the right. Theresult is that the linear expansion of B and C being unequal, C FLASH STEAM GENERATORS. 575 is drawn away from the bell crank, D, with the result that therod, B, is allowed to fall accordingly, decreasing or quite… … Fig. 418.—Sectional Elevation of the Blaxton Flash Generator. posed plane-profile coils of tubing, through which the water ispassed in series, from the lowest coil to the top, where it is takenoff as steam. As shown in the figure, the water fed from thepump passes direct to the centre of the lowest…
