Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 603

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 603 — passing over the burner, the other into the flattened andnested tubes of the generator. By this means the heat is increasedin ratio with the quantity of water injected, and the workingpressure may be regulated to any desired limit. When, however,the pressure has risen above a certain fixed point—it… … Fig. 433.—Serpollets Fuel and Water Pumps. The water pump, a, and thefuel pump, &, are operated from the lever, c. This is given an up-and-down movement by the link, rf, whose stroke is varied by the steppedcam, f, on which bears the roller, e, on the rod pivoted at i. The rotarymovement of the…

Automobiles

Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
