Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)

Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 605

An illustration from Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles, 1906, leaf 605 — hrough the pipe, D, which, how-ever, divides into two branches at the point, E, one portion of thewater being forced by the pump through the pipe, F, to the coilsof the generator, G. The pipe, F, has the air-chamber, H, lo-cated, as shown, between the pump and the steam generator. An- 592… … X ,Y.*»*__ Fig. 435.—Diagram of the Fuel and Water Feed System of the White SteamCarriage. A is the water pump operated from the crosshead of theengine, B. C is the water tank; D, a pipe leading to the pump, andbranching off at F, as shown, into J and N. F is the boiler feed pipeleading through the…

Automobiles

Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
