c 6C C % o O c3 o3 6 SIMPLE STEAM ENGINES. 611 gear. Single-acting steam engines, with from two to six cylin-ders, have also been brought to high perfection in Europe, beingmost familiar in the Gardner-Serpollet carriages. … Scientific Amebican, Fig. 449. —Diagram of the Locomobile Steam Carriage, showing parts in position. Ais tne boiler shell of copper; a, the winding of steel piano wire; B, the double cylinderengine; C, the adjustable strut, or distance rod; D, the compensating gear; E, pipeleading from engine to…
