Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 641
els is about 1 to 6. In additionto this pump, there is also an independent steam pump for use incase of emergency. 628 SBIP-PROPBLLED VHH1CLBS. The White Engine and Carriage.—Although the gasolinecarriage seems to have supplanted the steamer in a large num-ber of cases, a very desultory survey of… … Fig. 461 —The White Compound Steam Engine. The cylinders are encased inan aluminum jacket filled with asbestos lagging. The crank case and allparts which do not hear a working strain are of aluminum. The diaphragmregulator which acts upon the by-pabs valve is shown to the left, below thecylinder;…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
