Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 83
midway in the length of both. As shown in the diagramof this underframe, the motor is suspended between the rear axletube, which forms a sleeve over the rotating centre-divided axle,and the midway cross tube, already mentioned as forward of theaxle shaft The effect of a steady drive is obtained by… … ~~—e Fig. 67—Plan of the Duryea Three-wheeled Phaeton, showing the body frame used asattachment for all working parts, dispensing with the underframe entirely. uneven roadbeds, through the loose attachments of the oppositereach, in no way interferes with the interaction of the drivinggears. Herein,…
Automobiles
Internet Archive · Boston College Libraries · Public Domain Mark 1.0. Free to use for anything.
