Lange, David C. (David Christoph) · New York, John Wiley & sons, inc.; [etc., etc.] · leaf 27
ction of two planes inter-secting within the limits of the drawing. Let X and P be the intersecting planes. (Figs. 29 to32.) The intersection of the Horizontal Traces must be apoint common to both planes, and therefore a point commonto their line of intersection. The Vertical Projection ofthis… … POINTS, LINES AND PLANES 15
Shades and shadows · Geometry, Descriptive
