Mechanical drawing : a manual for teachers and students (1902)
Cross, Anson Kent · Boston : Ginn & Co. · leaf 136
nd right side views of a horizontal triangularprism; a section of the same by a plane at 60° to its horizontal face; alsothe development of its lateral faces. Draw the side view first, then the front and top views, then the line ofthe section at 60° in the front view, then the top view of the… … Fig, 83 1 ^ \ ^ 1° 2 \ \ < 4° A 8 C D
Mechanical drawing
Internet Archive · Boston Public Library · Public Domain Mark 1.0. Free to use for anything.
