Murray, Andrew, 1813-1872, Murray, Robert. Steam-ships, Creuze, Augustin Francis Bullock, 1800-1852 · Edinburgh : A. and C. Black · leaf 138
Fig. 13.—Doable Piston-rod Screw-engine, l^irect. Fig. 15.—Screw-engines in the Royal Nary, Direct. STEAM SHIPS. 121 … Steam Na- vigalion. The cylinder of the steam-engine, being that portion ofthe machine in which the poner is developed, must beconsidered as its principal member. Upon its dimensionsdepend, in some degree, the size of all the otiier parts ofthe engine, as well as its reputed powers, being called…
Naval architecture · Steamboats
