Fig. 117—Scratching a line with the scriber of the surface gauge Not every amateur mechanic can afford surface platesor expensive surface gauges. A very good substitute fora surface gauge is shown in Figs. 118 and 119. This is ahome-made affair, and, although not as accurate as a … Fig. 118—A simple, home-made surface gauge Measuring Instruments 103 commercial instrument, it mil suffice for ordinary work.In place of an expensive surface plate this little instru-r7\
