Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 131
the dog is shown at Fig. 165. Thistype of lathe dog is suitable for small bench lathes, buta different type is necessary for use on larger lathes aswill be explained later. The protruding arm of the lathedog rests in a slot cut in the face plate. A small set-screw on the lathe dog grips the work…
Machine-shop practice · Handicraft
