American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions (1914)

Colvin, Fred H. (Fred Herbert), 1867-1965, Stanley, Frank A. (Frank Arthur), b. 1874 · New York : McGraw-Hill book company ; London : Hill · leaf 643

An illustration from American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions, 1914, leaf 643
ndexing, Differential — Indexing with the index plate geared to the spindle, thus giving a differential motion that allows the indexing to be done with one circle of holes and with the index crank turned in the same direction, as in plain indexing.Indexing, Direct — Indexing work by direct use of…

Machine-shop practice
