Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 146
. The jaws, Avhich are adjust-able, are brought in contact Avith the rod and held in this Advanced Lathe Work 145 position by the screws. A close-up view of a simple,three-jawed center rest is sho\\ai in Fig. 180. A binderscrew is at the side of the center rest so that it can belocked in position… … Fig. 180—A three-jawed center rest screws showai. These screAvs can also be used in adjust-ing the jaws. If the screws are not used in this way,they should be turned until their ends come against theend of the jaws after the work is mounted. The jawsshould not be adjusted too tightly as this will…
Machine-shop practice · Handicraft
