Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 172
ral holes, those to accommodate the carriagebolts were drilled first to facilitate mounting the deviceupon the face plate. Two blocks cut from 2x4 stockwere used. The bolts seen protruding pass completelythrough these blocks and the blocks inturn are held tothe face plate by two more bolts, the… … Fig. 202—The use of blocks in mounting an angle plate to the faceplate for machining method of mounting mil be made very clear by referringto the sketch at Fig. 203. The angle plate should be jzSn r-t^
Machine-shop practice · Handicraft
