The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 419
Fig. 265. — Lengthwise Section of Corliss Cylinder, 26 by 48 in. Scale 1 to 21. … Fig. 266. — Cross Section of the Cyhnder in Fig. 265. Upper right-hand quartertaken at mid-length, the rest of the section through the head-end ports. The rerfult sought- and obtained is, that the valve shall have a widerand quicker movement in the direction for opening, a shorter andslower…
Steam-engines · Steam-turbines
