Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 291
finish it. The base of the motor can be finished at this point. 290 Shop Practice for Home Mechanics There is very little work to be done on it. The mechanicwill be able to test his accuracy in flat filing by bringingthe slide or raised portion of the base to as near a perfectplane as possible. The… … Fig. 299—How the motor base piece is ground in the drawing was placed between the motor and thebase just described. The block was ground out to ac-commodate the contour of the motor. This was done bythe aid of a small grinding wheel which happened to beat hand and which was about the same diameter…
Machine-shop practice · Handicraft
