Shop practice for home mechanics, use of tools, shop processes, construction of small machines. Contains a chapter also on theoretical mechanics and on miscellaneous information relative to shop work (1920)
Yates, Raymond F. (Raymond Francis), 1895- · New York, N. W. Henley Pub. Co. · leaf 90
Fig 97—Measuring and squaring at the same time stock is then found by applying the calipers to a ruleas shown in Fig. 99. If a piece of work is to be turneddowTi in the lathe to a diameter of 2 in, the calipers arefirst set with the scale. They are then applied to the Measuring Instruments 89 work… … Fig. 98—The use of calipers in determining the diameter of a rod upon actual use that it is not an easy matter to make anaccurate measurement with calipers unless they are
Machine-shop practice · Handicraft
