Shop sketching, a course of problems for mechanical drawing students (1919)
Windoes, Ralph Flagg, 1890- · Milwaukee, Wis., The Bruce publishing company · leaf 68
Supplementary Plate 5 66 SHOP SKETCHING Supplementary Plate 6 The working sketch of a tumbling shaft bracketis a good example of a simple bearing. Notice thaton the front view two full circles are represented,the large one being the hole bored out in the bodyof the bracket, and the small one the…
