A short treatise on the designing and construction of gearing and mill-work. Accompanied by an explanation of the construction and use of the odontograph of Prof. Willis .. (1873)

[Scott, David] engineer. [from old catalog] · New York, D. Appleton and company · leaf 28

An illustration from A short treatise on the designing and construction of gearing and mill-work. Accompanied by an explanation of the construction and use of the odontograph of Prof. Willis .., 1873, leaf 28
geering in iron-works, and the like, is greatly beyond the strength which acalculation of the power of the prime mover would indicate, and this is required to counteract the sud-den shocks which result from the chocking of rolls and the like. It may also be necessary to remark, that, in estimating… … In the teeth of wheels, it is of importance that the -whole be made of such strength as to sustain un-injured the greatest stress that is likely to come upon it in the course of working in the worst possibldiposition; that is to say, in the direction in which thestructure is capable of offering the…

Gearing · Mills and mill-work · Odontograph
