A short treatise on the designing and construction of gearing and mill-work. Accompanied by an explanation of the construction and use of the odontograph of Prof. Willis .. (1873)

[Scott, David] engineer. [from old catalog] · New York, D. Appleton and company · leaf 71

An illustration from A short treatise on the designing and construction of gearing and mill-work. Accompanied by an explanation of the construction and use of the odontograph of Prof. Willis .., 1873, leaf 71
to be made sufficiently strong for that purpose; but they ought obviously to be aslittle as possible increased in diameter beyond the required strength, and a proper allowance for wearto insure durability. In practice it is common to make the length of the gudgeon equal to the diameter.…

Gearing · Mills and mill-work · Odontograph
