An illustration from Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils, 1920, leaf 138 — Fig. 39. Starting Motor Taken ApartCourtesy of Westinghouse Electric <& Manufacturing Company 6000 5000 4000- i 3000 2000 WOO … 50 100 150 200 AMPERES INPUT TO MOTOR Fig. 40. Approximate Performance of Automobile Starting MotorCourtesy of Westinghouse Electric & Manufacturing Company 125 126 DESIGN OF SMALL MOTORS The following tabulation gives the principal design data: Armature Diameter 3.25 inches Gross length 1.625…
