Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)

Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 27

An illustration from Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils, 1920, leaf 27 — y-phase motor. When two-thirds full speed, or thereabouts, hasbeen reached, the starting winding is usually cut out by a centrif-ugally operated switch. In Figs. 8 and 9 is shown the WesternElectric type SA induction motor, which operates on this principle.Fig. 10 shows the Robbins & Myers… … P r P

Electric motors · Electric transformers · Electromagnets · Induction coils

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
