Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)
Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 319
and the service.The simplest kind of interrupter is the one shown in Fig. 42. Itcannot be easily adjusted for different speeds and is in generalslower than any of the other types. It is satisfactory, however,for small spark coils and medical coils. In Fig. 44 is shown the atonic interrupter, which… … Fig. 44. Atonic Interrupter 306 ELECTROMAGNETS AND COILS 67 adjusting screw C. The contact mechanism consists of the lever Dand the adjusting screw E. The advantage of this interrupter Ues inthe fact that when the clapper A is attracted to the core, it movessome distance before it touches the lever…
Electric motors · Electric transformers · Electromagnets · Induction coils
