Small motors, transformers, electromagnets; a practical presentation of design and construction data for small motors, small low- and high-tension transformers, electromagnets, and induction coils (1920)
Stoller, Hugh Montgomery, Austin, F. E. (Frank Eugene), 1873-, Seeger, Edwin Wilbur, 1892- joint author, American Technical Society · Chicago, American Technical Society · leaf 91
SIGN OF SMALL MOTORS the starting winding will be arranged as shown in Fig. 31, wherethose slots containing the larger number of conductors fit intothe slots which contain only one-half the full number of mainconductors. Forty-eight conductors are shown in Fig. 3L Theseare to be multipHed by a… … Fig. 31. Starting Winding for Western Electric Type SA, Form SI, Frame 165,Single-Phase Induction Motor 4 be high enough to secure a current which is as near in phase withthe line voltage as possible but low enough to give a substantialAalue of current. A good compromise is four times the…
Electric motors · Electric transformers · Electromagnets · Induction coils
