Yarn and cloth making; an economic study; a college and normal schools text preliminary to fabric study, and a reference for teachers of industrial history and art in secondary and elementary schools (1918)

Kissell, Mary Lois · New York, The Macmillian company · leaf 245

An illustration from Yarn and cloth making; an economic study; a college and normal schools text preliminary to fabric study, and a reference for teachers of industrial history and art in secondary and elementary schools, 1918, leaf 245
-shuttle. X DRAW LOOMDistinctive Characteristics First mechanism for elaborate figured weaving: oneoperating a compound system of shedding on the samewarp strands; the system applied to the Perfectedhand loom. Weft device for shedding: two separate shedding systemswith distinct functions —• a shaft… … Fig. 79. — Diagram Showing Action of Two Harness Systems A, Work accomplished by first harness which outlines on a large scale thepattern. B, Work accomplished by second harness which breaks up thispattern in detail. Outline Examples: Chinese draw loom; French draw loom.Implement — Draw loom. 1.…

Textile industry · Spinning · Weaving
