Spur and bevel gearing; a treatise on the principles, dimensions, calculation, design and strength of spur and bevel gearing, together with chapters on special tooth forms and methods of cutting gear teeth (1914)

New York, The Industrial press; [etc., etc.] · leaf 207

An illustration from Spur and bevel gearing; a treatise on the principles, dimensions, calculation, design and strength of spur and bevel gearing, together with chapters on special tooth forms and methods of cutting gear teeth, 1914, leaf 207 — aced in the top of the boxes for test pieces, andbefore the work is taken out of the box these pieces should behardened and broken to make sure that the depth of case isright. It is a well-known fact that nickel alloy steels require a longercarbonizing heat than straight-carbon steel, and in order… … _^^/>/// rTT-;. overflowtrough ^OUTLET TORETURN PIPE i©

Gearing
