Spur and bevel gearing; a treatise on the principles, dimensions, calculation, design and strength of spur and bevel gearing, together with chapters on special tooth forms and methods of cutting gear teeth (1914)
New York, The Industrial press; [etc., etc.] · leaf 44
ny other pitch, divide or multiply as directed in the table.The illustration, Fig. 10, shows the method applied to layingout a 2 diametral pitch gear. The odontograph for the cycloidalsystem may also be appHed to laying out teeth for internalgears. Odontograph Table for The Involute System. — To… … Machinery Fi^. II. Involute System Gear Teeth laid out by the Aid of Grants Odontograph inside the pitch Hne; then draw the faces of the teeth from thepitch line to the addendum Hne by using the face radius as givenin the table for involute teeth, and with centers located on the^base line. If the…
Gearing
