two separateelectrical coils. The diagram illustrates the prin-ciple. The two carbons are seen in black ; theupper one is movable, The current arrives at A.It divides, and the greater part goes through theFig. 211. Diagram low resistance coil M to a contact roller r> andof the Pilsen thence Dy…
