The standard manual of dynamos and practical application of dynamo-electric machinery (1915)
MacFadden, Carl K. [from old catalog], Ray, William D., [from old catalog] joint author · Chicago, Laird & Lee, inc. · leaf 42
amo itself might be used to excite its own field mag-nets and owing to a slight amount of residual magnet-ism, which always remains in a piece of iron after hav-ing once been magnetized, being present in the field THEORY OT? DYNAMOS. 37 magnets, this was easily accomplished, as shown infigure i6,… … FIGURE 17.—SHUNT WOUND DYNAMO. generally used in arc light dynamos, and others gener-ating a constant current of high voltage. The plan of a shunt winding is shown in figure 17,and is so called from the fact that the winding forms ashunt path around the armature. To make an effici-ent dynamo, the…
Electrical engineering · Electric machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
