The gasoline engine on the farm; a practical, comprehensive treatise on the construction, repair, management and use of this great farm power as applied to all farm machinery and farmer's work indoors and out .. (1913)

Putnam, Xenophon Whiting, 1867- · New York, The Norman W. Henley Pub. Co. · leaf 79

An illustration from The gasoline engine on the farm; a practical, comprehensive treatise on the construction, repair, management and use of this great farm power as applied to all farm machinery and farmer's work indoors and out .., 1913, leaf 79
rings and then spreading it over the cylinderwalls. Even a very brief failure of the supply, onaccount of a clogged oil tube or empty cup, may setthe piston or cylinder to cutting and render reboringnecessary; or disaster may come to the piston rings in-stead; as the oil is very quickly burned up,… … Fig. 19.—Piston Pin Oil Feed. 64. The Dirt Menace.—Cleanliness depends a greatdeal upon the cjuality of the lubricating oil used, but,even with the best of oil, the rings will become socoated in time with sticky or baked residue that theyno longer close or expand freely in the groove;…

Internal combustion engines · Farm engines

Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
