Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 113
Fig. 13. Diagram Showing Lap Angle andAngle of Lead … Fig. 14. Indicator Diagram ShowingEffect of No Lead Fig. 15. Indicator Diagram ShowingToo Early Admission and velocity of the reciprocating parts, it is evident that the amountof lead required will vary for different engines and for the same enginerunning at different speeds. The exact amount of…
Indicators for steam-engines · Steam-engines
