nder (seeFigs. 40 and 41), proceed as before. The eccentric will be found atE, Fig. 41, and the right and left valve circles will be located in thefirst and third quadrants, respectively. An examination of Figs. 38 to 41 will disclose the fact that toreverse an engine using an indirect valve, it is…
