Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 168
the eccentric rod EA is pivoted ablock which slides in a straight, slotted guide. The guide remainsstationary while the engine is running, but can be turned on its axisP to reverse the engine or to change the cut-off. P is a pivot whichis located on a horizontal line through $ in such a position… … Fig. 60. Diagram of Hackworth Radial Valve Gear through the horizontal position to full gear back (as shown bythe line BL) without moving the valve. It will be observed, there-fore, that the leads are constant for all positions of the guide. Thevalve rod running upward from C connects with the…
Indicators for steam-engines · Steam-engines
