Parts of a Microscope: B Base or foot; D Draw-tube; E Ocular or eye-piece; HA HandleI Joint for inclination; M Mirror: MH Head of the micrometer screw for fine adjustment;O Objective; P Pillar; PH Head of the Pinion for the coarse adjustment; R Rack of coarseadjustment; RN Revolving nose-piece; S… … The Microscope in Section with the Images: I, 2, 3, Beams of light to the mirror; CImage distance, i. e.: from eye-point, E-P, to virtual image (O4); CD Condenser diaphragm;EP Eye-point of ocular; Fi Upper focal plane of the objective; F2 Lower focal plane of theeye-piece; I, Mechanical…
Microscopy
