Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 31
icator Card Showing Effect ofChanging Connecting Pipe The indicator A and the cards obtained therefrom will be here-inafter designated as cylinder indicator and cylinder cards and it is 18 STEAM ENGINE INDICATORS assumed that this indicator will give indications true to the condi-tions in the… … -+TP/PE CARD -CYLINDER CARD Fig. 19. Indicator Card Showing Effect ofChanging Connecting Pipe the cylinder indicator and from the pipe indicator will be due entirelyto the pipe connections. Pipe connections of 5, 10, and 15 feet were used, the length ofpipe being measured from outside of the…
Indicators for steam-engines · Steam-engines
