Thermodynamics of the steam-engine and other heat-engines (1889)
Peabody, Cecil Hobart, 1855-1934 · New York, Wiley & Sons · leaf 315
Fig. 57. … Fig. 58. the terminal pressure in the small cylinder. This peculiarity ofthe back pressure in the small cylinder is due to the fact thatthe cranks of the engine are at right angles. In the test C,which has the cut-off at 0.465 of the stroke, there is a drop of TESTS OF SIMPLE AND COMPOUND ENGINES.…
Thermodynamics · Steam-engines · Heat-engines
