Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 35
a horizontal position. With this form of reducing motion, the cords may be led inany direction in a vertical plane from the sector and one or morecords may be led off to different indicators. The face of the sectorshould be true and the radius must have a value sufficient to give the required… … Fig. 27. Diagram Showing Principle ofBrumbo Pulley Example. Suppose it is desired tomake a reducing motion for a 10- by16-inch engine. Assume the length ofthe lever L to be 24 inches and the re-quired length of card D to be 4 inches. The length of stroke S is 16 inches.Designating the radius of the…
Indicators for steam-engines · Steam-engines
