Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 81
Fig. 47. Distorted Card Due to Binding Indicator Piston Tight Indicator Piston. The cards exhibited in Figs. 47, 48, and49 illustrate the distortion of the card which may occur when theindicator piston does not fit properly and binds, due to the indicator … Fig. 48. Distorted Card Due to Binding Indicator Piston parts not being put together properly. The indicator by means ofwhich these diagrams were obtained had the screw in the bottom ofthe piston run up so far that the piston rod did not fit down over theprojection on the piston, hence perfect…
Indicators for steam-engines · Steam-engines
