Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 85
Fig. 59. Effect of Faulty Valve Arrangement end of the stroke and the point where full admission occurs. Earlyadmission would be indicated in the same way, the exception being … Fig. 60. Card of Gas Engine Operating Under Full Load that the admission line would slope towards the line x y drawn at theend of the card, instead of away from it, as it does in the case illus-trated. When retarded admission occurs in a very large degree, thecurvature of the admission line is more…
Indicators for steam-engines · Steam-engines
