The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 392
Fig. 233. — Valve Setting with the Indicator. by the sound of the exhaust puffs. Through uncertainty as to thetype of valve, the rod length was at first altered in the wrong direc-tion, with the effect shown at II. Reversing this, and correcting inthe proper direction, the symmetrical steam…
Steam-engines · Steam-turbines
